Wind farm is a combination of Civil and electrical infrastructure works: We help in site development, laying the utilities, coordination with the utilities, infrastructure works, access roads, foundations, underground cabling, and substations.

Wind Farms, Europe (Various - 20+)

Location: Europe

Stage:      RIBA Stage 3 to 4

Scope:     Structural/ Civil and Utilities- BIM, Construction Documentation, Civil 3D and 2D Services

We at ODE consultants provides the complete works for BIM, Civil 3Dwork for the Wind form projects. We work with consultants and contractors to generate design and construction drawings.

  • Substation Buildings- IPP/ Grid/Modular- Structural BIM and Drawings

  • Site Layouts

  • Equipment Foundations

  • Utilities

  • Roads- Planning as per Equipment Supplier Guidelines, Surfaces, Layouts, Profiles and Alignment

  • Drainage- Clean and Dirty

bally2
ballyy1

Wind Farm, Co Kerry, Ireland

Length of road  -   4.9km

Stage - Detailed Design

Scope  of Work - Topography surface creation in Civil 3D

The Ballylongford Wind Farm site was consented in 2018. The consented site in North Kerry will consist of six turbines with a maximum tip height of 126.5m.
The new wind farm will have a 25-year operational life from the date of commissioning.

Hagshaw Windfarm Scottland

Application - Windfarm

Capacity - 79 MW with 14 New turbine

Scope - Design of access road and site services (Drainage, Cable, Spoil & water crossing) using Civil 3D and Infraworks

The original 16MW is now undergoing a process of repowering, becoming home to 14 new wind turbines with a combined capacity of over 79MW. The windfarm will be capable of producing around five times the amount of clean, green energy than before, from just over half the number of turbines. The Hagshaw Hill repowering project is part of Scottish Power Renewables’ wider ambition to maximise the efficiency of its existing sites by replacing older turbines with new, more powerful, and efficient models. With the repowering of the original turbines, once completed, the site will have capacity to power 66,000 homes every year.

hagshaw1
hagshaw2
hagshaw3
pigeon1
pigeon2
pigeon3

Pigeon Top Wind Farm Ireland

Application - Windfarm

Capacity - 37.7 MW with 9 turbines

Scope - Design of planning access road using Civil 3D and Infraworks

The Pigeon Top Wind Farm site is beside Energia’s existing Cornavarrow Wind Farm, which has been operational since 2018. The development will generate up to 37.8 MW of renewable energy - enough to meet the annual electricity needs of around 34,000 households. The new wind farm will have a 35-year operational life from the date of commissioning.

Castlebanny Wind Farm Ireland

Length of Road - 22KM

Stage - Tender Stage

Scope of Work - Topographical surface creation in CIVIL 3D

This project involves the development of a wind farm near Mullinavat, County Kilkenny, featuring a total of 21 wind turbines. The project is designed with a lifespan of 30 years, during which it will contribute significantly to local renewable energy generation. The final design layout has been carefully planned to optimize energy production while minimizing environmental impact. The strategic location of the site, coupled with the advanced turbine technology, will allow the wind farm to contribute significantly to Ireland's renewable energy targets, providing clean, sustainable energy to the local grid.
